Model A172.8-UG Series
Wall-Mounted, Universal Bi-Level Drinking Fountain - In-Unit Refrigeration (8GPH), ADA
These ADA-compliant, bi-level drinking fountains feature in-unit refrigeration and antimicrobial push buttons. Rough-ins match other manufacturers’ water coolers for easy replacement, and the Maintenance Advantage ® design makes access and service a breeze.
Electric Water Cooler Features
- Crisp, chilled water at 8 gallons (30.28 liters) per hour
- Universal Bi-Level allows for left-side or right-side high on the drinking fountain
- Each drinking fountain station features a single, uncomplicated, mechanical rectangular activation button
- Flexible, antimicrobial, non-squirt bubbler or stainless steel bubbler
- Available in galvanized steel with grey textured powder coat or all-stainless steel
- Child or Adult ADA Compliant when properly installed
- Chiller includes Water Leak Detection Auto Shut-Off Valve
Model Variations
- A172108F-UG | Textured Grey Finish Bottom, Flexible Bubbler
- A172108S-UG | Textured Grey Finish Bottom, Lead-Free Stainless Steel Bubbler
- A172408F-UG | All-Stainless Steel, Flexible Bubbler
- A172408S-UG | All-Stainless Steel, Lead-Free Stainless Steel Bubbler
Water Filter
The popular option provides a water filter for A171 and A172 Series water coolers. WF3EZ provides a 3,000-gallon (11,356 liters) capacity filter. This EZ Door® Filter option features a panel assembly that allows for fast and easy water filter changes without removing the shroud.
- Chlorine Reduction greater than 97.3%, 10,000 gallons (37,854.12 liters) @ 1.67 gallons (6.32 liters) per minute
- Lead Reduction Greater than 99.7%, 2,500 gallons (9,463.53 liters) @ 1.67 gallons (6.32 liters) per minute, lead reduction to one micron
- Complies with NSF/ANSI Standard 42+53
- Complies with NSF 42 - the standard regulates non-health related contaminant reductions, including reduction of chlorine, taste and odor, chloramine, particulate, iron, manganese, zinc, and total dissolved solids (TDS).
- Complies with NSF 53 - the standard regulates the reduction of over 50 health-related contaminants, including lead, Cryptosporidium, VOCs, and chromium.
- Cyst, Cryptosporidium, Giardia Reduction greater than 94.95%
- Total PFAS Reduction includes PFOA, PFOS, PFHpA, PFHxS, and PFNA
- Replacement filters are sold through Murdock
Downloads
Resource Type | Title | Description | File Size | Action | |
|---|---|---|---|---|---|
 | | Murdock Mfg - Pressure Water Coolers | 146 KB | ||
 | | ADA Self-Contained Universal Bi-Level Wall Mount Water Coolers [Model A172.8-UG | Standard (Rectangular Pushbutton), A172.8-UG-SO | Sensor-Activated, A172.8-UG-VR | Vandal Resistant Push Button] - includes parts manuals | 3 MB | ||
| | ADA Self-Contained Universal Bi-Level Wall Mount Water Cooler | 288 KB | ||
| | Option: 3,000-Gallon Capacity EZ Door® Filter | 924 KB | ||
| | Murdock Care and Cleaning Guide - for Stainless Steel and Enviro-Glaze® Powder Coated Products | 95 KB | ||
| | Murdock Mfg - Pressure Water Coolers | 219 KB | ||
| | Kwik Ship Brands: Murdock Mfg (pdf) | 401 KB | ||
| | Kwik Ship Brands are a new way to order products. These standardized items are stocked locally, replenished weekly, and available for quick delivery, ensuring you get what you need with minimal delay. | 4 MB | ||
| | Kwik Ship® Brands: Commercial Engineering Approval Form | 1 MB | ||
| | MM - Maintenace Advantage (pdf) | 6 MB | ||
| | Custom Colors, Logos & Graphics Brochure (pdf) | 671 KB | ||
| | Enviro-Glaze Color Chart Flyer (pdf) | 202 KB | ||
| | Indoor Water Coolers, Bottle Fillers and Drinking Fountains Brochure (pdf) | 3 MB | ||
| | Murdock Kwik Ship® vs Elkay, Oasis [A171108F-UG, A172108F-UG, A171408F-UG, A171408S-UG, A172408F-UG, A172408S-UG, BF11, BF12, BF12-BCD, BF11S, BF12S, BF12S-BCD, BFEZS168, BFEZS168-BCD, BF15, BF16, BF16-BCD, BF15S, BF16S, BF16S-BCD, A0004000-SK5, A000G000-SK5, WF3EZ, WF3000, RWF3000, RWF3000-20] Lit# L1001747 6/26 | 665 KB | ||
 | | Murdock® water fountains, bottle fillers, and hand washing stations are made from high-quality, durable stainless steel, one of the easiest materials to clean and disinfect. | 134 KB | ||
| | Video showing how to replace water filter on a Murdock Maintenance Advantage Drinking Fountain Models A17 Series) | 101 KB |
Specifications
| Mounting | Wall-Mounted |
| Material | Stainless Steel |
| Material Detail | Textured Grey, All-Stainless Steel |
| Compliances | ANSI/ASHRAE 18, UL Listed (US and Canada), CE complaint for 220 V electrical, Lead-Free Federal Law 111-380, cUPC, NSF/ANSI/CAN 61 |
| Refrigeration | In-Unit 8 GPH Refrigeration |
| Product Features | Universal bi-level - can be installed left high or right high, Auto-Stop (Servicing Strainer Shuts Off Water Supply), Maintenance Advantage® – Easy Maintenance Design, Chiller includes Water Leak Detection Auto Shut-Off Valve |
| Activation | Drinking fountain - rectangular button |
| Accessibility | ADA Compliant |
| Patent | US 12,410,592 B2 (Drop-down Filter), US 10,100,933 B2 (Auto-Stop Feature) |
| Style | A17 Series |
| No. of Stations | 2 |
| Brand | Maintenance Advantage®, EZ Door™ |
Options
Accessories
Image | Model | Description | Downloads | |
|---|---|---|---|---|
 | SK5 | Accessory: Skirt Assembly for ADA Bi-Level Water Cooler | ||
 | WB2 | Accessory: Wall Panel for Wall Mounted ADA Universal Bi-Level Handicap Fountain/Cooler - Orientation Right Unit Low | ||
 | WB3 | Accessory: Wall Panel for Wall Mounted ADA Universal Bi-Level Handicap Fountain/Cooler - Orientation Left Unit Low |
Miscellaneous
Image | Model | Description | Downloads | |
|---|---|---|---|---|
 | -220V | Option: Electrical 220 Volts | ||
 | LOGO | Option: Customize Graphics | ||
 | WF3EZ | Option: 3,000-Gallon Capacity EZ Door® Filter |
Models
A172108F-UG Textured Grey Finish/ Flexible Bubblers
A172108S-UG Textured Grey Finish/ Stainless Steel Bubblers
A172408F-UG All-Stainless Steel/ Flexible Bubblers
A172408S-UG All-Stainless Steel/ Stainless Steel Bubblers
Popular Options
-220V | 220 Volt / 50 Hz or 60Hz Compressor -SK5 | Cane Detection Skirt for Upper Unit -WF3EZ | 3000-Gallon EZ Door® PFAS Filter
See the submittal or options list
